Eaton 9PX 48V Lithium-ion Extended Battery Module (EBM) used with 9PX1500RT-L, 9PX1500RTN-L, 9PX1500GRT-L UPS, 1U Rack/Tower

$2,313.08

Brand: Eaton
Part Number (MPN): 9PXEBM48RT-L
UPC / GTIN: 743172105592
Datasheet: PDF

Eaton 9PX 48V Lithium-ion Extended Battery Module (EBM) used with 9PX1500RT-L, 9PX1500RTN-L, 9PX1500GRT-L UPS, 1U Rack/Tower

Toronto Stock: 3 available
Manufacturer Warehouse: 321 available
*Items typically ship within 3-4 weeks if stock at factory
Need project pricing? Add items to your cart to request a custom project quote.

Quick Specs

  • Connects to select expandable Eaton 9PX UPS systems for extended runtime
  • Daisy-chain connector supports additional battery packs for even longer runtime
  • Includes heavy-gauge cabling with high-current 48V DC connectors
  • Supports 1U rack mounting or upright tower installation using included accessories

Features

Backup Battery Module Gives Your Compatible Eaton UPS System Extended Runtime
The 9PXEBM48RT-L offers extended battery runtime when used in conjunction with Eaton’s 9PX1500RT-L, 9PX1500RTN-L and 9PX1500GRT-L 9PX UPS systems. It can also be daisy-chained for a maximum of four matching battery packs to deliver even longer extended-run operation. Heavy-gauge cabling with high-current DC connectors is included for safe, simple installation.

Supports 1U Rack or Tower Installation
This backup battery pack’s multi-use form factor supports mounting in 1U of space in EIA-standard 19-inch open frame racks or enclosures using the included 4-post rail kit and mounting brackets. Tower stands from a compatible UPS support optional upright configuration of the battery pack.

System Requirements

Compatible only with Eaton’s 9PX1500RT-L, 9PX1500RTN-L and 9PX1500GRT-L 9PX UPS systems

Package Includes

  • 9PXEBM48RT-L 48V Extended Battery Module
  • External battery cable
  • Rack-mounting hardware
  • Stabilizer bracket
  • Quick Start Guide
Weight 36.49 lbs
Dimensions 17.6 × 17.2 × 1.7 in
UPC Code

743172105592
Rack Depth

21
Brand

Input Phase

Single-Phase
Battery Type

Lithium-ion (LiFePO4)
DC System Voltage (VDC)

48
Battery Management

Integrated battery management system (BMS) for temperature regulation and life cycle monitoring
Primary Form Factor

Rackmount; Tower
Rack Height

1U
External Battery Pack Form Factor

Rack/Tower
Installation Form Factors Supported with Optional Accessories

2 post rackmount ( RK2PA )
Minimum Required Rack Depth (cm)

53.34
Unit Weight (kg)

16.56
Operating Temperature Range

32° to 104°F (0° to 40°C)
Relative Humidity

0-96% non-condensing
Product Certifications

cTUVus; NOM (Mexico); EN 62040-2; ICC-ES AC156 OSHPD Seismic Certified
Product Compliance

FCC Part 15 Class B (USA); RoHS
