Tripp Lite series Fixed Wall Mount for 45″ to 85″ TVs and Monitors – DWF4585X
$94.11
Tripp Lite series Fixed Wall Mount for 45″ to 85″ TVs and Monitors
Toronto Stock: 27 available
Need project pricing? Add items to your cart to request a custom project quote.
Quick Specs
- Fits most flat-panel displays from 45 to 85 in.
- Hangs out of sight for a sleek, professional appearance
- Adjustable mounting rails compensate for off-center wall studs
- Supports up to 200 lbs (90.7 kgs)
Overview
The VESA-compliant DWF4585X Fixed Wall Mount allows you to mount your flat-panel television, monitor or other display on the wall. Ideal for home theaters, classrooms, boardrooms, hotels, bars and restaurants, it fits most flat-panel displays from 45 to 85 inches. The low-profile mount is concealed behind the display to give a sleek, professional appearance. Frame is open for easy wall access. Mounting rails adjust horizontally to compensate for off-center wall studs. Built-in bubble level allows accurate display leveling. Durable all-metal frame with scratch-resistant powder-coated finish supports up to (90.7 kgs). Mounting hardware included. Conforms to VESA-compliant displays with any of the following mounting hole patterns: 200 x 200 mm, 200 x 300 mm, 200 x 400 mm, 300 x 200 mm, 300 x 300 mm, 300 x 400 mm, 400 x 200 mm, 400 x 300 mm, 400 x 400 mm, 500 x 300 mm, 500 x 400 mm, 600 x 300 mm, 600 x 400 mm, 800 x 300 mm and 800 x 400 mm.
Features
Mounts Your TV or Monitor to the Wall
- Fits most flat-panel televisions, monitors and other displays from 45 to 85 in.
- Ideal for home theaters, classrooms, boardrooms, hotels, bars and restaurants
- Mounts out of sight behind display for sleek, professional appearance
- Mounting hardware included
Durable Metal Construction
- Supports up to 200 lbs (90.7 kgs)
- Open frame allows easy wall access
- Adjustable mounting rails compensate for off-center wall studs
- Built-in bubble level for accurate display leveling
- Scratch-resistant powder-coated finish
VESA Compliance
- Supports the following VESA mounting hole patterns: 200 x 200 mm, 200 x 300 mm, 200 x 400 mm, 300 x 200 mm, 300 x 300 mm, 300 x 400 mm, 400 x 200 mm, 400 x 300 mm, 400 x 400 mm, 500 x 300 mm, 500 x 400 mm, 600 x 300 mm, 600 x 400 mm, 800 x 300 mm and 800 x 400 mm
Package Includes
- Wall plate
- (2) Adapter brackets
- (4) M5 x 14 screws
- (4) M6 x 14 screws
- (4) M6 x 30 screws
- (4) M8 x 20 screws
- (4) M8 x 30 screws
- (4) Washers
- (8) Small spacers
- (4) Big spacers
- (6) Anchor bolts
- (6) Concrete anchors
- (6) D6 washers
- Owner’s manual
| Weight | 7.3 lbs |
|---|---|
| Dimensions | 35.2 × 6.3 × 2 in |
| UPC Code | 037332186478 |
| Weight Capacity (kg) | 200.62 |
| Max Display Size | 85 |
| Brand | |
| Device Compatibility | Monitor/HDTV |
| Color | Black |
| Material of Construction | Steel |
| VESA Pattern (mm) | 200×200; 200×300; 200×400; 300×200; 300×300; 300×400; 400×200; 400×300; 400×400; 500×300; 500×400; 600×300; 600×400; 800×300; 800×400 |
| Motion | Fixed |
| Mounting Location | Wall |
| Degrees of Motion | Fixed |
| Minimum Screen Size (cm) | 114.3 |
| Maximum Screen Size (cm) | 215.9 |
| Maximum Weight Capacity (kg) | 91 |
| Number of Displays | 1 |
| Shipping Dimensions (hwd / cm) | 5.08 x 16.00 x 89.41 |
| Shipping Weight (kg) | 3.31 |
| Unit Dimensions (hwd / cm) | 43.99 x 84.84 x 3.61 |
| Unit Weight (kg) | 2.59 |
| Assembly Required | Yes |
| Cord Management | No |
| Tools Necessary | Yes |
| Product Compliance | RoHS; RoHS3; REACH |
| Product Warranty Period (Worldwide) | 5-year limited warranty |
