Tripp Lite series Cisco-Compatible GLC-SX-MMD 1000Base-SX SFP Transceiver, DDM, Multimode LC, 850nm, 550M

Quick Specs

• Cisco switch compatible…Comparable to GLC-SX-MMD=
• Compliant with SFP Multi-Source Agreement (MSA) standards
• 300 meter transmission distance using 62.5/125 MMF cabling
• 500 meter transmission distance using 50/125 MMF cabling

Overview

The N286-01GSX-MDLC SFP (mini-GBIC) transceiver module is designed for use with Cisco networking equipment, and is functionally equivalent to Cisco part number GLC-SX-MMD=. This transceiver is manufactured to meet or exceed the specifications of the original Cisco unit, and to comply with Multi Source Agreement (MSA) standards.

Features

• Cisco switch compatible…Comparable to GLC-SX-MMD=
• Compliant with SFP Multi-Source Agreement (MSA) standards
• 1000Base-SX transceiver supports data transfer rates up to 1.25Gbps
• 300 meter transmission distance using 62.5/125 Multimode cabling
• 500 meter transmission distance using 50/125 Multimode cabling
• 850nm wavelength VCSEL Laser
• Duplex LC Connector
• Electrical interface compliant with SFF-8431
• Supports Digital Diagnostic Monitoring (DDM)
• Hot-pluggable

System Requirements

For a list of compatible switches, see the Switch Compatibility document in the Resources section of this model’s web page, or in its Technical Support page.

Package Includes

• N286-01GSX-MDLC Transceiver
• Quick Start Guide
