Tripp Lite series MTP/MPO Patch Cable with Push/Pull Tabs, 12 Fiber, 40GbE, 40GBASE-SR4, OM3 Plenum-Rated – Aqua, 1M (3 ft.)

$188.66

Brand: Tripp Lite
Part Number (MPN): N844-01M-12-P
UPC / GTIN: 037332173713
Datasheet: PDF

Tripp Lite series MTP/MPO Patch Cable with Push/Pull Tabs, 12 Fiber, 40GbE, 40GBASE-SR4, OM3 Plenum-Rated – Aqua, 1M (3 ft.)

Manufacturer Warehouse: 44 available
*Items typically ship within 3-4 weeks if stock at factory
Need project pricing? Add items to your cart to request a custom project quote.

Quick Specs

  • Hi-density MTP/MPO 12-fiber connectors for reduced cabling
  • Push/Pull tab connectors offer maximum accessibility in high density installations; install / remove with one hand
  • OM3 rated 50/125 Multimode
  • Supports to 40GbE speeds

Features

  • MTP / MPO Push-Pull Connectors for Quick Fiber Optic connections
  • Push/Pull tab connectors offer maximum accessibility in high density installations; install / remove with one hand
  • 12 times the density of SC style connectors
  • High Density design cuts down on installation costs
  • 50/125 OM3 Rated Multimode Fiber, 850nm
  • Plenum rated jacket
  • Unique cable ID label for Quality Control and Traceability
  • Each cable 100% tested for low insertion loss and back reflection
  • Test data supplied with each cable
  • Custom lengths available

Package Includes

  • 1 Meter MTP / MPO Patch Cable, 12 Fiber, 40GbE Aqua OM3 Plenum
Weight 0.05 lbs
Dimensions 9 × 0.5 × 7 in
UPC Code

037332173713
Cord Length

3.31
Brand

Technology

Multimode
Optical Mode

OM3
Side A - Connector 1

12F MPO (FEMALE)
Side B - Connector 1

12F MPO (FEMALE)
Endface Polish

PC
Polarity

Type B (cross)
Cable Jacket Color

Aqua
Connector Color

Aqua; Black
Cable Jacket Material

PVC
Cable Jacket Rating

OFNP
Clad Diameter (microns)

125
Core Diameter (microns)

50
Number of Fibers

12
Cable Length (m)

1.01
Minimum Bend Radius

20 mm (Dynamic); 10 mm (Static)
Shipping Dimensions (hwd / cm)

17.78 x 1.27 x 22.86
Shipping Weight (kg)

0.02
Fiber Cable Length

1M (3.3 ft)
Operating Temperature Range

-4° to 140°F (-20° to 60°C)
Storage Temperature Range

-4° to 140°F (-20° to 60°C)
Operating Humidity Range

5% to 85% RH, Non-Condensing
Storage Humidity Range

35% to 65% RH, Non-Condensing
Network Compatibility

40 Gbps; 100 Gbps; 400 Gbps
Attenuation @ 850NM

3.0 dB/km
Insertion Loss

≤ 0.35 dB
Push/Pull Tabs

Yes
Product Compliance

RoHS; REACH
Product Warranty Period (Worldwide)

Lifetime limited warranty
