Tripp Lite series 40/100/400G Multimode 50/125 OM3 Fiber Optic Cable (8F MPO/MPO-PC F/F), Type-A Polarity, OFNP, Aqua, 30 m (98.4 ft.)

Name: Tripp Lite series 40/100/400G Multimode 50/125 OM3 Fiber Optic Cable (8F MPO/MPO-PC F/F), Type-A Polarity, OFNP, Aqua, 30 m (98.4 ft.)
Brand: Tripp Lite
SKU: N844A-30M-8-P
Price: 329.87 CAD
Availability: InStock

$329.87

Brand: Tripp Lite

Part Number (MPN): N844A-30M-8-P

UPC / GTIN: 037332294524

Datasheet: PDF

Tripp Lite series 40/100/400G Multimode 50/125 OM3 Fiber Optic Cable (8F MPO/MPO-PC F/F), Type-A Polarity, OFNP, Aqua, 30 m (98.4 ft.)

Manufacturer Warehouse: 66 available
*Items typically ship within 3-4 weeks if stock at factory

Need project pricing? Add items to your cart to request a custom project quote.

Quick Specs

OM3-rated cable recommended for 400 Gb speeds up to 100 meters (@ 1300 nm)
Backward compatible with 10/25/40/100 Gb networks to facilitate future-proofing
Aqua OFNP jacket provides fast, easy identification in a high-density application
Push/pull tab connectors allow convenient one-handed installation and removal

Features

40/100/400 GbE Cable Supports Higher Bandwidths for High-Density Data Networking
The N844A-30M-8-P is a premium multimode fiber optic cable that supports 400 Gb Ethernet speeds for transmitting data and voice signals over short distances. It is designed to support higher bandwidths for high-density patching between data center MDFs and IDFs in enterprise installations. This multimode 50/125 OM3 cable is an ideal choice for 100 Gb Ethernet applications up to 100 meters (328 feet) at 1300 nm. It is also backward compatible with 10 Gb and 25 Gb networks, so you can future-proof your current application for an eventual upgrade to 100 Gb or 400 Gb.

Aqua-Colored Jacket Helps Avoid Misidentification That Can Cause Costly Downtime
The OM3-rated cable has an aqua jacket to identify it as multimode in a high-density application and prevent it from becoming accidentally disconnected. The OFNP plenum-rated jacket complies with code requirements during commercial installations, making the N844A-30M-8-P ideal for network installers, facility integrators and government contractors. The MPO push-pull connectors allow easy one-handed installation and removal.

Easy to Pair with Eaton Tripp Lite Series Fiber Extenders
The N844A-30M-8-P is compatible with P580-Series termination kits for MPO fiber cabling, including P568-000-FBR (HDMI) and P580F-000 (DisplayPort), sold separately.

Package Includes

N844A-30M-8-P 40/100/400G Multimode 50/125 OM3 Fiber Optic Cable, Type-A Polarity, Aqua, 30 m (98.4 ft.)

Weight	0.54 lbs
Dimensions	0.5 × 10 × 12 in
UPC Code	037332294524
Cord Length	98.46
Brand	Tripp Lite
Technology	Multimode
Optical Mode	OM3
Mode Type	Multimode
Side A - Connector 1	8F MPO (FEMALE)
Side B - Connector 1	8F MPO (FEMALE)
Endface Polish	PC
Polarity	Type A (straight through)
Color	Aqua
Cable Jacket Color	Aqua
Connector Color	Aqua; Black
Cable Jacket Material	PVC
Cable Jacket Rating	OFNP
Cable Outer Diameter (OD)	3.0 mm
Clad Diameter (microns)	125.0
Core Diameter (microns)	50.0
Primary Coating Diameter (microns)	245.0
Number of Fibers	8
Cable Length (m)	30.01
Minimum Bend Radius	20 mm (Dynamic); 10 mm (Static)
Shipping Weight (kg)	0.24
Fiber Cable Length	30M (98.4 ft)
Operating Temperature Range	14° to 140°F (-10° to 60°C)
Storage Temperature Range	14° to 140°F (-10° to 60°C)
Relative Humidity	5% to 85% RH, Non-Condensing
Operating Humidity Range	5% to 85% RH, Non-Condensing
Storage Humidity Range	35% to 65% RH, Non-Condensing
Network Compatibility	40 Gbps; 100 Gbps; 400 Gbps
Wavelength	1300nm; 850nm
Attenuation @ 850NM	3.5 dB/km
Attenuation @ 1300NM	1.5 dB/km
Insertion Loss	≤ 0.50 dB
Return Loss	≧ 20 dB
Push/Pull Tabs	Yes
Optical Port	MPO/MTP
Product Compliance	RoHS; REACH
Product Warranty Period (Worldwide)	Lifetime limited warranty
