TAA SmartPro 120V 1kVA 800W Line-Interactive Sine Wave UPS, 1U Rack/Vertical, Network Card Options, USB, 6 Outlets

$1,251.80

Brand: Tripp Lite
Part Number (MPN): SM1000RM1UTAA
UPC / GTIN: 037332184184
Datasheet: PDF

TAA SmartPro 120V 1kVA 800W Line-Interactive Sine Wave UPS, 1U Rack/Vertical, Network Card Options, USB, 6 Outlets

Manufacturer Warehouse: 119 available
*Items typically ship within 3-4 weeks if stock at factory
Need project pricing? Add items to your cart to request a custom project quote.

Tripp Lite’s SM1000RM1UTAA is compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases. This intelligent, line-interactive sine wave rack/tower uninterruptible power supply prevents data loss, downtime and equipment damage due to power outages, voltage fluctuations and transient surges. Requires only two rack spaces (1U) in a standard rack enclosure. Large internal batteries offer 17 minutes half load runtime and 7 minutes at full load. Maintains regulated 120V nominal output without using battery power during brownouts and overvoltages from 83 to 147V. 1000VA/700 watt power handling capability and full time sine wave output supports networking, telecom and other sensitive electronic applications. Includes a total of 6 outlets arranged in 2 load banks that are individually controllable via software interface to reboot select equipment on demand or shed less significant loads to extend battery runtime for more critical equipment. Supports simultaneous remote monitoring of UPS and site power conditions via built-in network accessory card slot, USB and DB9 serial monitoring ports. Optional SNMPWEBCARD accessory enables remote monitoring of UPS as a managed device via network management console applications. Communications ports support messaging of detailed UPS operating parameters and line power status. Includes PowerAlert UPS monitoring and unattended shutdown software with management support for an unlimited number of network UPS systems. Built-in accessory slot supports SNMP with optional SNMPWEBCARD adapter. Emergency Power Off (EPO) interface offers option for instantaneous power-off of UPS and connected equipment in the case of fire or emergency. Multi-function audible alarms and set of 5 front panel LEDs offer at-a-glance notification of UPS and line power status. Network-grade AC surge suppression protects equipment from damage and performance problems resulting from transient surges and line noise. Attractive all-black color scheme. Two year warranty with $250,000 connected equipment insurance (USA & Canada only).

Weight 36 lbs
Dimensions 22.5 × 23.5 × 6.25 in
Form Factor
Color

Black

Cord Length

3

Brand

Input operation voltage (min)

83 V

Input operation voltage (max)

147 V

Input frequency

60 Hz

Output operation voltage (min)

120 V

Output operation voltage (max)

120 V

Audible alarm(s)

Yes

LED indicators

Yes

Operating temperature (T-T)

0 – 40 °C

Storage temperature (T-T)

-15 – 50 °C

Certification

UL 1778: 2014 R8.15 (5TH EDITION); CAN/CSA-C22.2 NO. 107.3-14

Width

444,5 mm

Depth

425,4 mm

Height

44,4 mm

Output frequency

60 Hz

Power factor

0,7

Power protection features

Over voltage, Under voltage

Typical backup time at full load

7 min

Typical backup time at half load

17 min

Battery recharge time

4 h

Cable length

3 m

Weight

14,5 kg

Hot-swap battery

Yes

Manual

Yes

AC outlets quantity

6 AC outlet(s)

AC outlet types

NEMA 5–15R

Cold start

Yes

Operating relative humidity (H-H)

0 – 95%

Rack capacity

1U

Storage relative humidity (H-H)

5 – 95%

Rack mount kit

Yes

Surge energy rating

480 J

Package width

596,9 mm

Package depth

571,5 mm

Package height

158,8 mm

Package weight

16,3 kg

Quantity per master (outer) case

1 pc(s)

Country of origin

Taiwan

Master (outer) case width

596,9 mm

Master (outer) case length

571,5 mm

Master (outer) case height

158,8 mm

Master (outer) case weight

16,3 kg
