Tripp Lite series USB-C to USB-C Full-Function Fiber Active Optical Cable (AOC) - USB 3.2 Gen 2 (10 Gbps), 8K, HDR, 4:4:4, 60W PD Charging, M/M, Black, 10 m (33 ft.)

Tripp Lite USB-C to USB-C Full-Function Fiber Active Optical Cable - USB 3.2 Gen 2 (10 Gbps), 8K, HDR, 4:4:4, 60W PD Charging, Black, 10 m - U420F-10M

Tripp Lite USB-C to USB-C Full-Function Fiber Active Optical Cable – USB 3.2 Gen 2 (10 Gbps), 8K, HDR, 4:4:4, 60W PD Charging, Black, 10 m – U420F-10M

Name: Tripp Lite USB-C to USB-C Full-Function Fiber Active Optical Cable - USB 3.2 Gen 2 (10 Gbps), 8K, HDR, 4:4:4, 60W PD Charging, Black, 10 m - U420F-10M
Brand: Tripp Lite
SKU: U420F-10M
Price: 310.05 CAD
Availability: InStock

$310.05

Brand: Tripp Lite

Part Number (MPN): U420F-10M

UPC / GTIN: 037332294401

Datasheet: PDF

Tripp Lite series USB-C to USB-C Full-Function Fiber Active Optical Cable (AOC) – USB 3.2 Gen 2 (10 Gbps), 8K, HDR, 4:4:4, 60W PD Charging, M/M, Black, 10 m (33 ft.)

Manufacturer Warehouse: 14 available
*Items typically ship within 3-4 weeks if stock at factory

Need project pricing? Add items to your cart to request a custom project quote.

Quick Specs

Supports USB 3.2 Gen 2 speeds up to 10 Gbps to ensure lightning-fast data transfers
Provides 60W power output for charging, syncing and powering the host device
Supports 8K @ 30 Hz or 4K @ 144 Hz for high-resolution gaming or video editing
Compatible with all USB-C, Thunderbolt 3 and Thunderbolt 4 computer ports
Fiber optic construction ideal for long-distance connections not supported by copper

Features

USB-C Fiber Optic Cable Combines Data Transfer and 8K/4K Video
This full-function active optical cable (M/M) securely connects the USB-C, Thunderbolt 3 or Thunderbolt 4 port on your desktop, laptop or notebook computer to a USB-C data or audio/video device, such as a storage device, media server or surveillance camera, located up to 10 meters (33 feet) away. It is ideal for high-end video conferencing, USB camera placement, 3D printers or high-resolution Pro AV devices, such as touchscreen displays, digital signage or travel displays that can be powered via USB-C PD charging.

Supports USB-C DisplayPort Alternate Mode for Converting Audio/Video Signals
By connecting the USB-C end to a source device that supports USB DisplayPort Alt Mode, you can output 8K/4K video and digital audio to a USB-C monitor, television or projector without installing special software drivers.

Transmits 8K and 4K Video with HDR and 4:4:4 Color
The U420F-10M supports Ultra HD 8K resolutions up to 7680 x 4320 at 60 Hz and 4K resolutions up to 3840 x 2160 at 144 Hz with 30-bit Deep Color. It also supports HDR (High Dynamic Range), providing a wide range of vibrant colors with richer contrast, brighter whites and deeper blacks that pop on your display. HDCP 2.2 encryption allows you to stream 4K content with no loss in resolution. This cable also supports uncompressed 4:4:4 chroma subsampling for top-level PC gaming or using your HDTV as a PC monitor.

Transfers Data and Powers Devices for Innovative Workspace Applications
The full-function U420F-10M connects your MacBook Pro, Windows laptop or other USB-C device to the USB-C port on Logitech or Poly video conferencing cameras, touchscreen displays and smartboards. It supports USB 3.2 Gen 2 data transfer rates up to 10 Gbps. It also provides power output up to 20V 3A (60W), which is enough to power most laptops, as well as connected equipment or travel displays. The plug-and-play cable is compatible with Thunderbolt 3 and Thunderbolt 4 devices, as well as USB-C.

System Requirements

Host device with USB-C, Thunderbolt 3 or Thunderbolt 4 port (USB 3.2 Gen 2 compatibility required to achieve USB 3.2 Gen 2 speeds)
Host device must support DisplayPort Alt Mode 1.4
Display must support video resolutions up to 8K @ 60 Hz or 4K @ 144 Hz
Host device and charger must support PD charging up to 20V 3A (60W)

Package Includes

U420F-10M USB-C to USB-C Fiber Active Optical Cable, M/M, Black, 10 m (33 ft.)

Weight	1.76 lbs
Dimensions	8.86 × 9.25 × 1.54 in
UPC Code	037332294401
Cord Length	32.81
Brand	Tripp Lite
Technology	Thunderbolt; USB 3.x
Cable Type	Active
Number of Monitors Supported	1
Supported Resolutions	3840×4320 (4K); 7680×2160 (8K)
Max Supported Video Resolution	7680 X 4320 @ 30HZ
Max Supported Color Depth	30-bit Deep Color
HDR Support	Yes
3D Video Supported	Yes
Chroma Sub Sampling	4:2:0; 4:2:2; 4:4:4
EDID Support	Yes
DisplayPort Alt Mode	Yes
DSC Support	Yes
USB Power Delivery (PD) Charging Support	Yes
USB Power Delivery (PD) Charging Specification	20V/3A; 60W
Side A - Connector 1	USB C (MALE)
Side B - Connector 1	USB C (MALE)
Connector Plating	Gold
Contact Plating	Gold
Connector Style	Straight
Total Charging Amps	3A
Total Charging Watts	60
Compatible Devices	Laptop; Smartphone; Tablet; Video Game Console
Color	Black
Material of Construction	TPE
Cable Jacket Color	Black
Connector Color	Black
Cable Jacket Material	TPE
Cable Jacket Rating	VW-1
Cable Outer Diameter (OD)	6.5mm
Cable Length (m)	10.00
Cable Length (cm)	500
Shipping Weight (kg)	0.80
Unit Packaging Type	Box
Operating Temperature Range	-4° to 158°F (-20° to 70°C)
Storage Temperature Range	32° to 122°F (0° to 50°C)
Relative Humidity	5% to 90% RH, Non-Condensing
Operating Humidity Range	5% to 90% RH, Non-Condensing
Storage Humidity Range	5% to 90% RH, Non-Condensing
Power Provided to Connected Device(s)	60W (20V/3A)
EDID Compatible	Yes
Consumer Electronics Control (CEC) Supported	Yes
USB Specification	USB 3.2 Gen 2 (Up to 10 Gbps)
Data Transfer Rate	10 Gbps
Displayport Specification	1.4; 2.1
HDCP Specification	2.2
Product Compliance	CE (Europe); FCC (USA); REACH; RoHS; UKCA; WEEE
Product Warranty Period (Worldwide)	3-year limited warranty
