Tripp Lite series USB-C to Gigabit Ethernet Vertical Network Adapter (M/F) – USB 3.1 Gen 1, 10/100/1000 Mbps, Black

$18.89

Brand: Tripp Lite
Part Number (MPN): U436-000-GB
UPC / GTIN: 037332238085
Datasheet: PDF

Tripp Lite series USB-C to Gigabit Ethernet Vertical Network Adapter (M/F) – USB 3.1 Gen 1, 10/100/1000 Mbps, Black

Manufacturer Warehouse: 111 available
*Items typically ship within 3-4 weeks if stock at factory
Need project pricing? Add items to your cart to request a custom project quote.

Quick Specs

  • Connects to a wired 10/100/1000 Mbps network where Wi-Fi is weak or unavailable
  • Vertical USB-C plug orientation prevents adjacent ports from being blocked
  • More convenient, less expensive than installing or upgrading an internal Ethernet card
  • Reversible USB-C plug connects in either direction for immediate no-fuss use
  • Plug-and-play operation with no software required for easy, immediate installation

Features

USB-C to Gigabit Ethernet Adapter Connects to Your Laptop’s USB-C or Thunderbolt 3 PortThis USB Type-C to Gigabit Ethernet NIC Network Adapter (M/F) allows your computer, tablet, laptop, notebook, MacBook, Chromebook, Ultrabook or smartphone to connect to a wired Ethernet network. Connect the USB-C plug to your device’s USB-C or Thunderbolt 3 port, and connect the RJ45 port to a UTP cable (such as N201-Series, sold separately). Access True Gigabit Speeds Without an Ethernet CardIdeal for settings in which no Wi-Fi is available or when a wired connection offers faster speeds, this USB 3.1 Gen 1 adapter lets you enjoy true 10/100/1000 Mbps Ethernet speeds for fast data transfers and audio/video streaming. Stream audio and video without buffering, upload family photos to the Cloud and transfer large files with confidence.Vertical Molding Prevents Blockage of Adjacent PortsThe USB-C input’s vertical orientation results in a slimmer adapter that maximizes space around the device’s ports and prevents them from being blocked. Unlike traditional USB cables that connect in only one direction, the reversible USB-C male connector plugs into a USB-C or Thunderbolt 3 port in either direction for a fumble-free connection every time.Ready to Use Right from the Package, So You Can Plug and Play ImmediatelyThe plug-and-play USB Type-C to RJ45 adapter is specifically designed for use with the MacBook, Google Chromebook Pixel and other laptops, tablets and devices equipped with a USB-C or Thunderbolt 3 port. It requires no software, drivers or external power (a driver may be required if your computer is running a version of Windows older than 10.1). The palm-sized one-piece molding fits into your pocket, briefcase or laptop bag for connecting to a wired Gigabit Ethernet network anywhere.

System Requirements

  • PC, tablet, laptop, notebook, MacBook, Chromebook, Ultrabook or smartphone with USB-C or Thunderbolt 3 port
  • Windows, Mac or Chromium operating system

Package Includes

  • U436-000-GB USB-C to Gigabit Ethernet Vertical Network Adapter (M/F), Black
  • Owner’s manual
Weight 0.0474 lbs
Dimensions 0.5 × 7 × 9 in
UPC Code

037332238085

Brand

Technology

Cat5/5e; Cat6

Bus Powered

Yes

Side A - Connector 1

(1) USB C (MALE)

Side B - Connector 1

(1) RJ45 (FEMALE)

Contact Plating

Gold

LED Indicators

Green (Data Transmission), Orange (Power)

Color

Black

Material of Construction

ABS, PBT

Unit Packaging Type

Polybag

Unit Weight (kg)

0.01

Operating Temperature Range

32° to 104°F (0° to 40°C)

Storage Temperature Range

5° to 122°F (-15° to 50°C)

Relative Humidity

0-85% non-condensing

Network Compatibility

1 Gbps (Gigabit)

IEEE Standards Supported

802.1q; 802.3; 802.3az; 802.3u; 802.3x

USB Specification

USB 3.1 Gen 1 (up to 5 Gbps)

Full Duplex Support

Yes

Driver Required

No

Product Compliance

RoHS; CE (Europe); REACH; FCC (USA)

Product Warranty Period (Worldwide)

3-year limited warranty
