Tripp Lite series USB-C to DisplayPort 1.4 Active Adapter Cable (M/M), UHD 8K/30 Hz or 4K/144 Hz, Black/Silver, 6 ft. (1.8 m)

Name: Tripp Lite series USB-C to DisplayPort 1.4 Active Adapter Cable (M/M), UHD 8K/30 Hz or 4K/144 Hz, Black/Silver, 6 ft. (1.8 m)
Brand: Tripp Lite
SKU: U444-006-DP8SE
Price: 36.81 CAD
Availability: InStock

$36.81

Brand: Tripp Lite

Part Number (MPN): U444-006-DP8SE

UPC / GTIN: 037332255600

Datasheet: PDF

Tripp Lite series USB-C to DisplayPort 1.4 Active Adapter Cable (M/M), UHD 8K/30 Hz or 4K/144 Hz, Black/Silver, 6 ft. (1.8 m)

Manufacturer Warehouse: 79 available
*Items typically ship within 3-4 weeks if stock at factory

Need project pricing? Add items to your cart to request a custom project quote.

Quick Specs

Ideal for future-proofing your current A/V application in anticipation of an 8K upgrade
Converts audio/video signals from sources supporting USB DisplayPort Alt Mode
Supports UHD resolutions up to 8K @ 30 Hz for enhanced video without latency
Reversible USB-C plug connects in either direction for immediate no-fuss use
Uni-directional plug-and-play cable directs signals only from USB-C to DisplayPort

Features

USB-C to DisplayPort Adapter Cable Supports Top of the Line Video Output
This high-speed USB Type-C to DisplayPort adapter supports audio/video data transfer speeds up to 8.2 Gbps per-lane (32.4 Gbps total) bandwidth for high-end AV applications. The cable is capable of transmitting video at specifications including 7680 x 4320 (8K) @ 30 Hz and 3840 x 2160 (4K x 2K) @ 144 Hz when connected to the USB-C port of a host that supports DisplayPort Alt Mode 1.4.

Ideal for High-Bandwidth Audio/Video Work and Beyond
The U444-006-DP8SE is capable of supporting high bandwidth applications like editing high-resolution images or video, viewing high-definition video content or playing video games at the highest settings. While practical for future-proofing applications for 8K content, the cable is backwards compatible with DP 1.2 Alt Mode signals for existing hardware.

Ready to Use Right from the Package, So You Can Plug and Play Immediately
The plug-and-play USB Type-C to DisplayPort cable requires no software or external power. Just connect the USB-C plug to the USB-C or Thunderbolt 3 port on a source device that supports DisplayPort Alternate Mode, and connect the DisplayPort plug to your display.

System Requirements

Source device with USB-C or Thunderbolt 3 port that supports USB DisplayPort Alternate Mode
Display device with DisplayPort input
Both source and display devices must be compatible with 8K standards to watch 8K video

Package Includes

U444-006-DP8SE USB-C to DisplayPort Adapter Cable, M/M, Black/Silver, 6 ft.

Weight	0.154 lbs
Dimensions	0.5 × 7 × 9 in
UPC Code	037332255600
Cord Length	6
Brand	Tripp Lite
Product Type	Active Cable
Technology	DisplayPort
Cable Type	Active
Resolutions Supported	Supports maximum resolutions up to 7680 x 4320 (8K) at 30 Hz, or 3840 x 2160 (4K) at 144 Hz
Supported Resolutions	3840×4320 (4K); 7680×2160 (8K); 1280×720 (720p); 1920×1080 (1080p); 3840×2160 (4K); 5120×2880 (5K); 7680×4320 (8K)
Max Supported Video Resolution	7860 x 4320 (8K) @ 30Hz
Max Supported Color Depth	48-bit Deep Color
3D Video Supported	Yes
DSC Support	Yes
Side A - Connector 1	USB C (MALE)
Side B - Connector 1	DISPLAYPORT (MALE)
Contact Plating	Gold
Color	Black; Gray
Material of Construction	TPE
Cable Jacket Color	Black
Cable Jacket Material	TPE
Cable Outer Diameter (OD)	4.2mm
Cable Length (m)	1.83
Unit Packaging Type	Polybag
Unit Weight (kg)	0.07
Operating Temperature Range	32° to 113°F (0° to 45°C)
Storage Temperature Range	14° to 158°F (-10° to 70°C)
Operating Humidity Range	10% to 85% RH, Non-Condensing
Storage Humidity Range	5% to 90% RH, Non-Condensing
USB Specification	USB 3.0 (up to 5 Gbps); USB 3.1 Gen 1 (up to 5 Gbps)
Displayport Specification	1.2; 1.4
HDCP Specification	2.2
Product Compliance	CE (Europe); FCC (USA); REACH; RoHS; UKCA; WEEE
Product Warranty Period (Worldwide)	3-year limited warranty
