Tripp Lite series 4K HDMI Audio De-Embedder/Extractor with TOSLINK and 3.5 mm Stereo Output, 5.1 Channel, HDCP, 4K 30Hz, 6-in. (15.24 cm)

Quick Specs

• Built-in 6 in. HDMI cable connects to audio/video source
• Supports multi-channel audio up to 5.1 surround sound
• Features 3.5 mm stereo and TOSLINK optical audio outputs
• Transmits UHD video resolutions up to 3840 x 2160 (4K x 2K)
• Powered via USB Micro-B connection

Features

Extracts Audio from an HDMI Signal and Sends It to a Separate Audio System

• Recommended for connecting HDMI source to speakers that don’t have HDMI input
• 3.5 mm stereo and TOSLINK optical outputs connect to analog or digital non-HDMI audio equipment
• LED indicates the unit is receiving power or transmitting an audio/video signal
• Built-in 6 in. HDMI cable connects to audio/video source
• Included 3 ft. USB Micro-B cable provides power to the unit

Versatile Audio Options

• Supports 2-channel stereo and multi-channel audio up to 5.1 surround sound
• Supports uncompressed, such as LPCM, and compressed audio, including DTS and Dolby Digital

Vibrant UHD Video

• Transmits UHD video resolutions up to 3840 x 2160 (4K x 2K) @ 30 Hz
• Supports 24-bit True Color (8 bits per channel) at 4K x 2K
• Supports 36-bit Deep Color (12 bits per channel) at 1080p
• Supports optional 3D formats up to 300 MHz
• Complies with HDCP 1.4 standards

Package Includes

• P130-06N-AUDIO UHD 4K x 2K HDMI Audio De-Embedder/Extractor
• USB Micro-B cable, 3 ft.
• Owner’s manual
