Tripp Lite series SmartOnline Maintenance Bypass for Select 5kVA to 6kVA SmartOnline UPS Systems, 2 L6-30R and 2 L6-20R Outlets, 0U, TAA – SUPDMBP6K

Name: Tripp Lite series SmartOnline Maintenance Bypass for Select 5kVA to 6kVA SmartOnline UPS Systems, 2 L6-30R and 2 L6-20R Outlets, 0U, TAA - SUPDMBP6K
Brand: Tripp Lite
SKU: SUPDMBP6K
Price: 707.14 CAD
Availability: InStock

$707.14

Brand: Tripp Lite

Part Number (MPN): SUPDMBP6K

UPC / GTIN: 037332282859

Datasheet: PDF

Tripp Lite series SmartOnline Maintenance Bypass for Select 5kVA to 6kVA SmartOnline UPS Systems, 2 L6-30R and 2 L6-20R Outlets, 0U, TAA

Manufacturer Warehouse: 208 available
*Items typically ship within 3-4 weeks if stock at factory

Need project pricing? Add items to your cart to request a custom project quote.

Quick Specs

Isolates UPS from connected loads for maintenance without powering down equipment
Designed for 0U mounting to save space and increase airflow in a crowded rack
Compatible with SmartOnline SU5000RT and SU6000RT Series UPS systems

Features

Compatible with Select 5kVA/6kVA SmartOnline UPS Systems
The SUPDMBP6K works with the SmartOnline® SU5000RT, SU5000RTF, SU6000RT SU6000RTF, and SU6000RT3UTAA UPS systems (it comes included with the SU5000RTMB, SU6000RTMB, SU5000RTFMB and SU6000RTFMB). The bypass switch transfers the load to utility power in case of an overload or internal fault in the UPS. This allows you to service or replace the UPS without powering down any connected equipment or risking costly downtime. Two NEMA L6-20R and two NEMA L6-30R dongle outlets allow load connection. The SUPDMBP6K supports 0U mounting to save space and increase airflow in a crowded rack enclosure. AC input connection options include a terminal block for hardwire input/output or use of a NEMA L6-30P cord (10-foot cord included with compatible UPS models).

System Requirements

Compatible with SmartOnline SU5000RT, SU5000RTF, SU6000RT, SU6000RTF and SU6000RT3UTAA UPS systems
Comes included with SU5000RTMB, SU6000RTMB, SU5000RTFMB and SU6000RTFMB UPS systems

Package Includes

SUPDMBP6K Maintenance Bypass
Input/output UPS cable set
(2) Cable glands
Mounting hardware
Quick start guide

Weight	11.24 lbs
Dimensions	13.66 × 8.46 × 9.45 in
UPC Code	037332282859
Amps	25
Brand	Tripp Lite
UPS Type	On-Line
Accessory Type	Bypass Panel; Bypass Panel (Rack-Mount)
Accessory Class	UPS Accessories
Nominal Input Voltage(s) Supported	200V AC; 208V AC; 220V AC; 230V AC; 240V AC
UPS Input Connection Type	Hardwire; L6-30P
Voltage Compatibility (VAC)	200; 208; 220; 230; 240
Frequency Compatibility	50 / 60 Hz
Output Circuit Breakers	20A, double pole, branch rated, 250V
Output Receptacles	(1) Hardwire; (2) L6-20R; (2) L6-30R
Output Nominal Voltage	200/208/220/230/240 VAC
Switches	Manual bypass switch, make-before-break, two position rotary switch (UPS and Bypass); Normal AC Source Input switch (line, load)
LED Indicators	Green = UPS; Red = Bypass
Material of Construction	Metal
Form Factors Supported	Rear Rackmount; Tower; Wallmount
Unit Weight (kg)	2.50
Operating Temperature Range	32° to 104°F (0° to 40°C)
Storage Temperature Range	-15° to 60°C (5° to 140°F)
Relative Humidity	0-95% non-condensing
Input Amp(s)	25
Product Certifications	CSA (Canada); UL 1778
Product Compliance	RoHS; Trade Agreements Act (TAA)
Product Warranty Period (U.S. & Canada)	2-year limited warranty
