Tripp Lite series USB 2.0 Ethernet NIC Adapter – 10/100 Mbps, RJ45, Black
$22.07
Tripp Lite series USB 2.0 Ethernet NIC Adapter – 10/100 Mbps, RJ45, Black
Toronto Stock: 3 available
Need project pricing? Add items to your cart to request a custom project quote.
Quick Specs
- Connects you to a wired Ethernet network when Wi-Fi is weak or unavailable
- Supports USB 2.0 speeds to ensure efficient data transfers
- Sustains full 10/100 Mbps network speeds for fast Ethernet browsing
- Works with most laptops and PCs running Windows, Mac or Linux
- USB 2.0 Ethernet adapter powered via USB, so no external power supply is required
Features
Connects Your USB Device to a Wired Ethernet Network without an Internet Card InstalledThis USB to Ethernet adapter allows you to instantly connect your computer, laptop, tablet or other USB-compatible device to a wired 10/100 Mbps Ethernet network, even if your device has no NIC (Network Interface Controller) installed. The adapter is a more convenient, less expensive way to go online than opening your device and installing an internal Ethernet card.Plug and Play with No Power Supply NeededThis USB 2.0 Ethernet adapter offers access to an Ethernet network when Wi-Fi is unavailable or when a wired connection offers faster speeds. Just connect the built-in USB cable to your device’s USB port (which also powers the adapter), and wait for the installation process to finish (you may have to reboot your computer). Then, connect the RJ45 port to a LAN port using a Cat5e/6 network cable (such as N201-Series Cat6 UTP patch cable, sold separately). The adapter works with Windows, Mac and Linux operating systems. It is backward compatible with USB 1.1 devices.Delivers Full Ethernet PerformanceThe compact USB to Ethernet adapter supports full 10/100 Mbps network speeds and USB 2.0 speeds, allowing you to transfer data quickly and stream audio and video. It’s compliant with IEEE 802.3, 802.3u, 802.3ab and 802.3az standards. It supports full duplex with IEEE 802.3x flow control and half duplex with backpressure flow control. LEDs indicate successful data transfers.
System Requirements
- IBM-compatible Pentium PC or Mac with 233 MHz or faster
- 64 MB RAM or more
- Computer or laptop with USB port
- Windows (through 10), Mac (through 10.10/10.11) or Linux Kernel (2.6.14 and later) OS
Package Includes
- U236-000-R USB 2.0 Ethernet NIC Adapter
- Quick Start Guide
| Weight | 0.08 lbs |
|---|---|
| Dimensions | 3.94 × 4.72 × 0.79 in |
| UPC Code | 037332163127 |
| Brand | |
| Technology | Cat5/5e; Cat6; USB 2.0 (High Speed) |
| Country/Region | Global |
| Bus Powered | Yes |
| Product Length (in.) | 7.5 |
| Power Consumption (Watts) | 0.75 |
| Side A - Connector 1 | USB A (MALE) |
| Side B - Connector 1 | RJ45 (FEMALE) |
| Connector Plating | Nickel |
| Color | Black |
| Material of Construction | ABS, PVC |
| Cable Jacket Rating | VW-1 |
| Cable Outer Diameter (OD) | 3.0MM |
| Unit Dimensions (hwd / cm) | 1.6 x 2.7 x 6.0 |
| Unit Packaging Type | Box |
| Unit Weight (kg) | 0.02 |
| Operating Temperature Range | 32° to 158°F (0° to 70°C) |
| Storage Temperature Range | 14° to 176°F (-10° to 80°C) |
| Relative Humidity | 10% to 90 % RH, Non-Condensing |
| BTUs | 2.6 BTU/Hr |
| Operating Humidity Range | 10% to 85% |
| Storage Humidity Range | 5% to 90% |
| Network Compatibility | 100 Mbps (Fast Ethernet) |
| IEEE Standards Supported | 802.3; 802.3ab; 802.3az; 802.3u; 802.3x |
| USB Specification | USB 2.0 (up to 480 Mbps) |
| Ethernet Support | Yes |
| Auto MDIX Support | Yes |
| Full Duplex Support | Yes |
| Suspend Mode Support | Yes |
| Remote Wakeup Support | Yes |
| Driver Required | Yes |
| Recommended Category Cable | Cat5/Cat5e/Cat6 Cables |
| Product Compliance | RoHS; CE (Europe); REACH; FCC (USA) |
| Product Warranty Period (Worldwide) | 3-year limited warranty |
