Tripp Lite series External 36V 2U Rack/Tower Battery Pack for Select UPS Systems (BP36V15-2U)

Name: Tripp Lite series External 36V 2U Rack/Tower Battery Pack for Select UPS Systems (BP36V15-2U)
Brand: Tripp Lite
SKU: BP36V15-2U
Price: 1007.48 CAD
Availability: BackOrder

$1,007.48

Brand: Tripp Lite

Part Number (MPN): BP36V15-2U

UPC / GTIN: 037332119919

Datasheet: PDF

Tripp Lite series External 36V 2U Rack/Tower Battery Pack for Select UPS Systems (BP36V15-2U)

Status: On Backorder (Contact us for lead times)

Need project pricing? Add items to your cart to request a custom project quote.

Quick Specs

Extends the runtime of compatible 36V UPS Systems
Supports 2U rack-mount installation; 4-post installation accessories included
Options for 2-post rack-mount, tower and wall-mount installation available

Overview

BP36V15-2U rack/tower external battery pack offers extended battery runtime when used in conjunction with expandable 36V rack-mount and tower UPS systems. Includes heavy-gauge cabling with high-current DC connector for safe, simple installation. Included mounting accessories support 2U rack-mount installation in 4-post racks. Options for 2-point front-rail mounting, 2-post center-mounting, wall-mount and upright tower installation available.

Compatible with SMART1200XLHG, SMART1500RMXL2Ua, SMART1500XL, SMX1200XLHG, SMX1500XLRT2U and other UPS systems that specify the use of this battery pack.

Features

Offers extended-run UPS operation when used in conjunction with compatible 36V DC UPS systems
Includes heavy-gauge cabling with high-current DC connectors for simple installation
Included mounting brackets support rack-mount installation in 4-post racks using only 2 rack spaces (2U)
UPDHDEARKIT option supports two-point front-rail rack-mount installation without rear supports
2POSTRMKITWM option supports balanced two-point center-mounting in 2-post equipment racks
2POSTRMKITWM option also enables wallmount installation
2-9USTAND option enables upright tower placement
NOTE: LIMIT OF 1 BP36V15-2U PER UPS, SEE BP36V42-3U or BP36V27-2US FOR MULTI-PACK COMPATIBILITY

Package Includes

BP36V15-2U external battery pack with attached DC cabling
4 post compatible mounting hardware
Owner’s manual

Weight	57.81 lbs
Dimensions	23.4 × 20.2 × 8.9 in
UPC Code	037332119919
Rack Depth	17
Brand	Tripp Lite
Input Phase	Single-Phase
DC System Voltage (VDC)	36
UPS Connection	Grey 2-point connector
Typical Battery Lifespan	4-6 years typical
Material of Construction	Steel
Rack Height	2U
External Battery Pack Form Factor	Rack/Tower
Installation Form Factors Supported with Optional Accessories	2 post rackmount ( 2POSTRMKITWM ); 4 post rackmount short-depth ( 4POSTRAILKITWM ); Tower ( 2-9USTAND ); Wallmount ( 2POSTRMKITWM )
Minimum Required Rack Depth (cm)	43.18
Optional Mounting Accessory Notes	Optional 2-9USTAND enables upright tower UPS placement; 2POSTRMKITWM enables wall-mount and 2-post rackmount installation; 4POSTRAILKITWM enables installation in 4-post short-depth racks from 14.5 to 23.5 inches (368 to 597mm)
Shipping Dimensions (hwd / cm)	22.61 x 51.31 x 59.44
Shipping Weight (kg)	26.22
Unit Dimensions (hwd / cm)	8,89 x 44,45 x 33,66
Unit Weight (kg)	20.41
Mounting Details	Included 4POSTRAILKIT mounting bracket enables installation in 4 post racks from 20.5 to 36 inches (521 to 914mm)
Product Compliance	CE (Europe); RoHS
Product Warranty Period (U.S. & Canada)	2-year limited warranty
WEXT1G	Extended Warranty and Technical Support for Select Products – KVM, PDUs, Inverters
WEXT2G	Extended Warranty and Technical Support for Select Products – KVM Switches, PDUs, Power Inverters
WEXT3G	Extended Warranty and Technical Support for Select Products – KVM, PDUs, Power Inverters
TLWEBN72XX7000BC	2-Year Onsite Service Contract for 0-7000 VA Smart, SMX, SU External Battery Modules (EBMs)
TLWEBN75XX7000BC	5-Year Onsite Service Contract for 0-7000 VA Smart, SMX, SU External Battery Modules (EBMs)
Part Number	Description
TLWEBN73XX7000BC	3-Year Onsite Service Contract for 0-7000 VA Smart, SMX, SU External Battery Modules (EBMs)
